Designed for use with liquids, consult Dixon for specific recommendations
COUPLERS AND ADAPTERS
RDA2030BL
RDA2030BL - Boss-Lock Cam & Groove Type DA Jump Size Coupler x Adapter
Attributes
| Maximum Operating Pressure | |
|---|---|
| Weight |
4.1 lb
|
| Break Quantity |
0
|
| Optional Package/Box Quantity |
0
|
| Material |
316 Stainless Steel
|
| Seal |
Nitrile Rubber
|
| Coupler Size |
2"
|
| Adapter Size |
3"
|
Details
Applications
Available Options
Other gasket types are available, contact Dixon.
Construction
- Nitrile Rubber gasket
- Produced as a welded fabrication
How It Works
- To make a connection, simply slide the adapter into the coupler and with normal hand pressure, press the cam levers down.
- Uncoupling is as quick and simple as coupling. Just lift the cam arms and remove the adapter.
Note
In reducing couplings, the coupler is the first size in the part number.
Safety Notes
- Under no circumstances should cam and groove couplings be used for compressed air or steam service!
- Pressure rating recommendations are based on the use of mating Dixon fittings at ambient temperature 70°F (21°C) with a standard seal installed. For use at elevated temperature or other unusual operating conditions, consult Dixon.
Specifications
Produced to interchange with all product produced to Commercial Item Description A-A-59326D
WARNING: This product contains lead, a chemical known to the State of California to cause cancer and birth defects or other reproductive harm.
